Designed with the contractor in mind

Listening to contractor feedback, Luceco has redeveloped many of its Luceco Lighting and BG Electrical product lines to make installation quicker, easier and more versatile in application.

Two of the ranges recently redeveloped are the Luceco FTYPE Compact LED downlights and the BG Fortress circuit protection range, both of which are now available.



An FTYPE upgrade

Luceco’s new FTYPE Compact range is an upgrade to its market-leading FTYPE range of LED downlights. With enhanced crystalline optics, the latest Samsung chips are all packed into a more compact unit for more versatility, particularly in low or obstructed ceiling voids.

“There are several features we’ve further developed within our FTYPE Compact range to make them quicker and easier to install,” said Simon Shenton, head of LED lighting product development at Luceco. “Our Speedfit loop-in loop-out push fit terminals allow for cable to be installed in NEL-NEL order, eliminating cable cross-over for quick and orderly installation. What’s more, the terminals can be used with both solid and stranded cables, removing the need to specify different products for each cable type. This is also a major benefit of our Clip&fit cable clamp housing, which tightly secures both solid and stranded cable.” Simon continued: “To reduce the likelihood of installation damage to plasterboard around the fitting aperture, our range is supplied with rubber shrouds on the clips and magnetic bezels that snap into place without requiring removal of the whole unit.”

A wide range of decorative bezels are available to suit every aesthetic, easily swapped to suit later changes in décor. All downlights in the range offer 100 lumens per watt output, are NHBC Certified for I-JOIST applications, 30-60-90 minute fire rated and Parts L, C and E compliant, with the 4W versions Part L exempt.

Similar to the original FTYPE, the new compact range includes fixed, adjustable and a new regressed version, which includes a regressed optic that sets the LEDs further into the downlight. This creates a lower glare and softer feel within the space illuminated. The range also includes the Dim2Warm and Colour Changing versions, providing varying lighting colour temperature options to suit different environments and preferences.

For more information, visit www.ftype-compact.com

Feeding back on Circuit Protection

Another product range that has undergone many recent changes is the BG Fortress circuit protection range. Over the past 18 months, Luceco’s product development team have worked alongside contractors to upgrade this range of products.

“Helping contractors make their installation quicker and easier has been one of the key drivers behind our ongoing design changes,” said David Cleaver, senior product manager for BG Electrical. “The recent changes have largely been focused on the construction and internal wiring of the consumer unit. We have addressed this by changing the internal wiring configuration making it a lot easier for the incoming and outgoing cables to be installed, using sonic welded cables instead of large bulky ferrules.”

“We have included a quick release DIN rail and offset incomer that allows more space around the top, sides and back of the DIN rail, and entries to dress the cable. Extra support has been added to the DIN rail to make it easier and more stable when torquing the device terminals.”

The range includes combi-style screws, so the contractor only needs to use one screwdriver for installation, with backed-out and retained terminal screws preventing the inconvenience of losing screws. To improve accuracy, an integrated spirit level helps contractors check the board is level, bringing convenience and simplifying the installation process; particularly useful when working with one pair of hands. Floating busbars are included which can be cut to size and configured for the installation requirements, offering maximum flexibility for the contractor.

All these key additions are as a result of contractor feedback, making the Fortress consumer units quicker and easier to install.

With great flexibility and a highly customisable range of devices that include A Type RCD’s (including 100A), A Type RCBO’s, SPD’s and variable board configurations, contractors can tailor their requirements to meet the latest regulations and almost any application.

For more information, visit www.bg-fortress.uk
